Description
Operating weight: 10.800~11.100 kg
Standard bucket: 2.0m³Bucket variation: 1.5 – 3.0m³
Rated Power: 110 kW (148 hp / 150 ps) at 2,000 rpm
Cycle Time: 9.2 s
Tipping Load – Straight: 7,900 kg
Tipping load – articulated: 7,000 kg
Bucket breakout force: 100 kn
Maximum discharge height: 2912mm
Reach at maximum discharge height: 1.173mm
Engine: Yuchai – YCA05K150-M300
Emissions: Tier III / Stage IIIA
Length with bucket lowered: 7.175mm
Width over tires: 2.295mm
Cabin height: 3,300mm
Turning Radius, Outside Tire: 5.113mm
Fuel tank: 190 L
